Helical Solutions
647
H45AL-S-20750
Specifications
| Number Of Flutes | 2 |
|---|---|
| Coating/Finish | ZPLUS |
| Short Description | H45AL-S-20750 End Mills for Aluminum - 2 Flute - Square - 45° Helix |
| Shank Diameter | 0.7500" (3/4) |
| Overall Length | 4.0000" (4) |
| Center Cutting | true |
| Metric | N |
| LOC Multiple | (1x) |
| Coolant Through | N |
| Long Description | 0.7500" (3/4) Cutter DIA x 0.7500" (3/4) Shank DIA x 1.0000" (1) Length of Cut x 4.0000" (4) Overall Length Carbide 45° Helix Square End Mill for Aluminum, 2 Flutes, ZPLUS Coated - (H45AL-S-20750) |
| Length of Cut | 1.0000" (1) |
| Cutter Diameter | 0.7500" (3/4) |
| Shank Length | 3.0000" (3) |
