Helical Solutions
86288
HMAF-AL-40500-08-T30
Specifications
| Coating | NPLUS |
|---|---|
| Coolant Through | N |
| Long Description | 0.5000" (1/2) Cutter DIA x 0.5000" (1/2) Shank DIA x 16.0000" Major Radius x 0.0625" (1/16) Tip Radius x 0.2500" (1/4) Corner Radius x 0.4375" (7/16) Length of Cut x 3.0000" (3) Overall Length Carbide Taper Multi-Axis Finisher for Aluminum, 4 Flutes, NPLUS Coated - (HMAF-AL-40500-08-T30) |
| Shank Diameter | 0.5000" (1/2) |
| Short Description | HMAF-AL-40500-08-T30 End Mills for Aluminum - Multi-Axis Finishers - 4 Flute - Taper Form |
| Flutes | 4 |
| Weldon Flat | N |
| Overall Length | 3.0000" (3) |
| Cutter Diameter | 0.5000" (1/2) |
| Metric | N |
| Length of Cut | 0.4375" (7/16) |
| Center Cutting | true |
| Corner Radius | 0.2500" (1/4) |
| Included Angle | 60 |
