IngersollUsa
2912366
9M2L-06R01
Specifications
| Cutting Edge Angle | 60 |
|---|---|
| Overall Length | 76.2 |
| FamilyName | 9M2L - 60° Heavy Duty Face Mil |
| Coolant | 0 |
| Coolant-2 | No |
| Subapplication Name | Facing |
| Profile Angle | 0 |
| Depth of Cut Max | 19.329 |
| Application Name | Milling |
| Body Diameter | 194.437 |
| Cutting Diameter | 152.4 |
| Hub Diameter | 0 |
| Eff. Teeth | 6 |
| Bolt Circle Diameter | 0 |
| Bore Diameter | 38.1 |
| Main Application | ML |
