Iscar
2301324
DGFH 45-5
Specifications
| Long Description | Double-ended parting and grooving blades carrying DO-GRIP and HELI-GRIP double-ended inserts. Blades with coolant channels are designated with "C". |
|---|---|
| Short Description | DGFH-45-5 ISCAR DO-GRIP BLADE |
| APP1Name | Ext. Grooving |
| FamilyName | DGFH |
| Coolant | No |
| Base Length | 8.8580 |
| COO | Israel |
| Blade Height | 1.7720 |
| Weight (OZ) | 12.27513 |
| Width (Inch) | 2.48 |
| Blade Width | 0.1570 |
| Measurement Type | Inch |
