Iscar
3308187
QNMG 431-TF IC830
Specifications
| Coating/Finish | AlTiN+TiN |
|---|---|
| Material | Carbide |
| Included Angle | 80 degrees |
| Style | QNMG |
| Short Description | ISCAR QNMG-431-TF-IC830 |
| Long Description | Double-sided inserts with four 80° corners, positive rake angle that varies along the edge to negative in order to prevent chipping. Special design reduces cratering. Used for carbon and alloy steel, stainless steel and high temp. alloys. |
| Unit Of Measure | Imperial |
| Shape | Q#MG |
| Country of Origin | Israel |
| Base Item Number | Turning Indexable Inserts |
| Family Short Description | Double-Sided Inserts with Four 80° Corners for General Applications |
| Height | 0.39 Inch |
| Product Type | Industrial Supplies |
| Unit of Measure | Imperial |
| Weight | 0.37 OZ |
| Width | 1.57 Inch |
| APP1Name | Ext. 80° Q#MG 95° Approach |
| FamilyName | QNMG-TF |
| Weight (OZ) | 0.3739 |
| Width (Inch) | 1.57 |
| Cutting Edge Material | Carbide |
| Measurement Type | Inch |
