Iscar
3411460
SCD0359-1863-0394 ACP5FL IC608
Specifications
| Coating | AlTiCrSiN |
|---|---|
| Long Description | Solid carbide drills with coolant holes, drilling depth 5xD (available in North America only) |
| Material | Carbide |
| Short Description | ISCAR 23/64 5XD CARB/IC806 COOLANT DRILL 61x103 M10sh |
| Shank Diameter | 0.3940" |
| Flute Length | 0.0575" (1.460 mm) |
| APP1Name | Drilling |
| Overall Length | 4.0550" |
| FamilyName | SCD-ACP5FL (5XD) |
| COO | USA |
| Weight (OZ) | 0.28219 |
| Diameter | 0.3590" |
| Width (Inch) | 4.57 |
| Cutting Edge Material | Carbide |
| Measurement Type | Inch |
