Iscar
3602481
C4 SVJCR-27050-16
Specifications
| Short Description | C4-SVJCR-27050-16 ISCAR CAPTO/HSK/KM -ISO TURN TOOLS |
|---|---|
| Long Description | 93° lead angle screw lock tools with CAMFIX (ISO 26623-1 standard) exchangeable shanks carrying 35° rhombic inserts with 7° clearance angle. |
| Shank Size | C4 |
| APP1Name | Ext. 35° Diamond 93° Approach |
| FamilyName | C#-SVJCR/L |
| COO | Israel |
| Insert Shape | 35° Diamond |
| Weight (OZ) | 12.16931 |
| Width (Inch) | 2.09 |
| Coolant Hole | No |
| Measurement Type | Inch |
