Iscar
3603316
PDJNL 16-4-JHP
Specifications
| Short Description | PDJNL-16-4-JHP ISCAR JET HP LINE HOLDER (1/8"-28 BSPP) |
|---|---|
| Shank Width | 1.0000 |
| Long Description | Lever lock tools with channels for high pressure coolant, carrying 55° negative rhombic inserts. |
| APP1Name | Ext. 55° Diamond 93° Approach |
| Overall Length | 6.0000 |
| FamilyName | PDJNR/L-JHP |
| Shank Height | 1.0000 |
| COO | Israel |
| Insert Shape | 55° Diamond |
| Weight (OZ) | 30.194 |
| Width (Inch) | 2.17 |
| Coolant Hole | Yes |
| Measurement Type | Inch |
