Iscar
3603473
PTGNL 12-3X
Specifications
| Short Description | ISCAR PTGNL-12-3X 3/4x4.1/2 LH TOOLHOLDER (NOTES) |
|---|---|
| Shank Width | 0.7500 |
| Long Description | 91° lead angle lever lock external turning tools carrying negative triangular inserts. |
| APP1Name | Ext. 60° Triangle 91° Approach |
| Overall Length | 4.5000 |
| FamilyName | PTGNR/L-X |
| Shank Height | 0.7500 |
| COO | Israel |
| Insert Shape | 60° Triangle |
| Weight (OZ) | 12.94533 |
| Width (Inch) | 0.98 |
| Coolant Hole | No |
| Measurement Type | Inch |
