Iscar
6494333
GDMY 840 IC428
Specifications
| Long Description | Utility, double-ended inserts. Used for heavy duty turning, profiling and grooving. Maximum machining depth is 1.0". |
|---|---|
| Short Description | GDMY-840-IC428 ISCAR CG "M" TYPE INSERTS |
| Insert Width | 0.3150 |
| Min. Turning Feed | 0.0126 |
| Insert Designation | GDMY |
| APP1Name | Ext. Grooving |
| FamilyName | GDMY (full radius) |
| Max. Turning Feed | 0.0264 |
| COO | Israel |
| Work Material | Steel+Hardened Metals+Cast Iron |
| Coating | TiC+Al2O3 |
| Weight (OZ) | 0.71252 |
| Width (Inch) | 2.2 |
| Cutting Edge Material | Carbide |
| Measurement Type | Inch |
| Radius | 0.1570 |
