Jergens
49504
RECEIVER BUSHING, 35MM FACE MT, BALL LOCK, BLB-35-RC
Specifications
| Long Description | Jergens Ball Lock® Face Mount Receiver Bushings are generally utilized in blind hole applications (Slip Fit). Specifications: - Material: 4340 Steel - Finish: Black Oxide - Heat Treat: 50-54 RC - Operating Temperature Range: -20°F to 400°F (-30°C to 200°C) Note(s): - Cap Screws supplied with Ball Lock® Face Mount Receiver Bushings - Installed bushings should be approximately 0.012" (0.3mm) below subplate surface. |
|---|---|
| Shank Diameter | 35 mm |
| Material | 4340 Steel |
| Operating Temperature Range | -20°F to 400°F (-30°C to 200°C) |
| Mount Type | Face Mount |
| Series | Ball Lock® Face Mount Receiver Bushings |
| Bullet 1 | Ball Lock® |
| Finish | Black Oxide |
