M.A. Ford
11156250C
10117 TICN 9/16 4 FLUTE
Specifications
| Shank Type | Straight |
|---|---|
| Overall Length (Inch) | 3-1/2 |
| Number Of Flutes | 4 |
| Material | Carbide |
| Coating/Finish | TiCN |
| Diameter (Inch) | 9/16 |
| Unit Of Measure | Fractional |
| Helix Angle | 30 degrees |
| Short Description | 10117 TICN 9/16 4 FLUTE |
| Shank Diameter | 9/16 Inch |
| Series | TuffCut GP |
| Flute Length | 1-1/8 Inch |
| End Grind | Square |
| GTIN | 697604101174 |
| Country of Origin | USA |
| Base Item Number | 11156250C |
| Product Type | Industrial Supplies |
| Shank Diameter (Inch) | 9/16 |
| Unit of Measure | Fractional |
| Trade Name | TuffCut GP |
| Number Of Flutes (Right Hand) | 4 |
| Diameter (Decimal Inch) | 0.5625 |
