M.A. Ford
11162991C
10123 16MM DIA 0.5MM CR TICN
Specifications
| Number Of Flutes | 4 |
|---|---|
| Coating/Finish | TiCN |
| Material | Carbide |
| Overall Length (Metric) | 89 |
| Diameter (Inch) | 0.63 |
| Short Description | 10123 16MM DIA 0.5MM CR TICN |
| Unit Of Measure | Metric |
| Shank Diameter | 16 mm |
| Flute Length | 30 mm |
| Overall Length | 89 mm |
| Helix Angle | 30 degrees |
| Shank Diameter (Metric) | 16.0 |
| Series | TuffCut GP |
| Shank Type | Straight |
| Corner Radius (Metric) | 0.5 |
| GTIN | 697604101235 |
| Country of Origin | USA |
| Base Item Number | 11162991C |
| Product Type | Industrial Supplies |
| Unit of Measure | Metric |
| Trade Name | TuffCut GP |
| Number Of Flutes (Right Hand) | 4 |
| Diameter (Decimal Inch) | 0.6299 |
| Corner Radius | 0.50R |
| End Grind | Corner Radius |
