M.A. Ford
12178745
52472 12178740 WITH 2.0MM CORN
Specifications
| Number Of Flutes | 2 |
|---|---|
| Coating/Finish | Uncoated |
| Material | Carbide |
| Overall Length (Metric) | 102 |
| Diameter (Inch) | 0.79 |
| Short Description | 52472 12178740 WITH 2.0MM CORN |
| Unit Of Measure | Metric |
| Shank Diameter | 20 mm |
| Flute Length | 38 mm |
| Overall Length | 102 mm |
| Helix Angle | 30 degrees |
| Shank Diameter (Metric) | 20.0 |
| Series | TuffCut GP |
| Shank Type | Straight |
| Corner Radius (Metric) | 2 |
| GTIN | 697604524720 |
| Country of Origin | USA |
| Base Item Number | 12178745 |
| Product Type | Industrial Supplies |
| Unit of Measure | Metric |
| Trade Name | TuffCut GP |
| Number Of Flutes (Right Hand) | 2 |
| Diameter (Decimal Inch) | 0.7874 |
| Corner Radius | 2.00R |
| End Grind | Corner Radius |
