M.A. Ford
15811800R012N3A
15526 3MMX6MMX5MMX50MM .3MM CR
Specifications
| Number Of Flutes | 4 |
|---|---|
| Coating/Finish | ALtima 52 |
| Material | Carbide |
| Overall Length (Metric) | 50 |
| Diameter (Inch) | 0.12 |
| Short Description | 15526 3MMX6MMX5MMX50MM .3MM CR |
| Unit Of Measure | Metric |
| Shank Diameter | 6 mm |
| Flute Length | 5 mm |
| Overall Length | 50 mm |
| Helix Angle | 35 degrees/38 degrees |
| Shank Diameter (Metric) | 6.0 |
| Series | TuffCut DM |
| Shank Type | Straight |
| Corner Radius (Metric) | 0.3 |
| Neck Length (Metric) | 9 |
| GTIN | 697604155269 |
| Country of Origin | USA |
| Base Item Number | 15811800R012N3A |
| Product Type | Industrial Supplies |
| Unit of Measure | Metric |
| Trade Name | TuffCut DM |
| Number Of Flutes (Right Hand) | 4 |
| Diameter (Decimal Inch) | 0.1181 |
| Corner Radius | 0.30R |
| End Grind | Corner Radius |
