M.A. Ford
17740602A
17757 13/32X7/16X15/16X2.75X.0
Specifications
| Number Of Flutes | 4 |
|---|---|
| Coating/Finish | ALtima |
| Material | Carbide |
| Overall Length (Inch) | 2-3/4 |
| Diameter (Inch) | 13/32 |
| Short Description | 17757 13/32X7/16X15/16X2.75X.0 |
| Unit Of Measure | Fractional |
| Shank Diameter | 7/16 Inch |
| Corner Radius (Decimal) | 0.02 |
| Flute Length | 15/16 Inch |
| Overall Length | 2-3/4 Inch |
| Helix Angle | 35 degrees/38 degrees |
| Series | TuffCut XR |
| Shank Type | Straight |
| GTIN | 697604177575 |
| Country of Origin | USA |
| Base Item Number | 17740602A |
| Product Type | Industrial Supplies |
| Unit of Measure | Fractional |
| Shank Diameter (Inch) | 7/16 |
| Trade Name | TuffCut XR |
| Number Of Flutes (Right Hand) | 4 |
| Diameter (Decimal Inch) | 0.4062 |
| Corner Radius | .015R |
| End Grind | Corner Radius |
