M.A. Ford
22436610
24671 9.30MM DIN 338 10% CARB
Specifications
| Coolant Fed | No |
|---|---|
| Number Of Flutes | 2 |
| Overall Length (Metric) | 125 |
| Diameter (Inch) | 0.37 |
| Material | Carbide |
| Diameter (Metric) | 9.3 |
| Unit Of Measure | Metric |
| Diameter | 9.30 mm |
| Flute Length | 81 Inch |
| Shank Type | Straight |
| Helix Angle | 21 degrees |
| Series | Twister GP |
| Shank Diameter | 9.30 mm |
| Shank Diameter (Metric) | 9.30 |
| Included Angle | 118 degrees |
| Number Of Flutes (Right Hand) | 2 |
| Specification | DIN 338 |
| Country of Origin | USA |
| Base Item Number | 22436610 |
| Coolant-Thru | No |
| Product Type | Industrial Supplies |
| Unit of Measure | Metric |
| Through Coolant | No |
| Trade Name | Twister GP |
| Diameter (Decimal Inch) | 0.3661 |
| Shank Diameter (mm) | 9.30 mm |
