M.A. Ford
22961020
23022 15.5MM 3 FLUTE DRILL
Specifications
| Coolant Fed | No |
|---|---|
| Number Of Flutes | 3 |
| Overall Length (Metric) | 133 |
| Diameter (Inch) | 0.61 |
| Material | Carbide |
| Diameter (Metric) | 15.5 |
| Unit Of Measure | Metric |
| Diameter | 15.50 mm |
| Flute Length | 83 Inch |
| Shank Type | Straight |
| Helix Angle | 30 degrees |
| Series | Twister AL |
| Shank Diameter | 16 mm |
| Shank Diameter (Metric) | 16.00 |
| Included Angle | 150 degrees |
| Number Of Flutes (Right Hand) | 3 |
| Specification | DIN 6537 L |
| Country of Origin | USA |
| Base Item Number | 22961020 |
| Coolant-Thru | No |
| Product Type | Industrial Supplies |
| Unit of Measure | Metric |
| Through Coolant | No |
| Trade Name | Twister AL |
| Diameter (Decimal Inch) | 0.6102 |
| Shank Diameter (mm) | 1.60 cm |
