M.A. Ford
CXDCR 1530AP
07069 CXD DRL 15.3MM COOL REG
Specifications
| Coolant Fed | Yes |
|---|---|
| Number Of Flutes | 2 |
| Overall Length (Metric) | 133 |
| Diameter (Inch) | 0.6 |
| Material | Carbide |
| Diameter (Metric) | 15.3 |
| Unit Of Measure | Metric |
| Diameter | 15.30 mm |
| Flute Length | 83 mm |
| Shank Type | Straight |
| Helix Angle | 30 degrees |
| Series | Cyclone XD |
| Shank Diameter | 16 mm |
| Shank Diameter (Metric) | 16.00 |
| Included Angle | 140 degrees-142 degrees |
| Number Of Flutes (Right Hand) | 2 |
| Specification | DIN 6537 L |
| Country of Origin | USA |
| Base Item Number | CXDCR 1530AP |
| Coolant-Thru | Yes |
| Product Type | Industrial Supplies |
| Unit of Measure | Metric |
| Through Coolant | Yes |
| Trade Name | Cyclone XD |
| Diameter (Decimal Inch) | 0.6024 |
| Shank Diameter (mm) | 1.60 cm |
