M.A. Ford
CXDCS1406AP
06789 CXD 9/64 3X COOLANT DRL
Specifications
| Flute Length (Inch) | 0.787 |
|---|---|
| Material | Carbide |
| Number Of Flutes | 2 |
| Shank Type | Straight |
| Helix Angle | 30° |
| Through Coolant | Yes |
| Overall Length (Decimal Inch) | 2.44 |
| Shank Diameter (Inch) | 5/32 |
| Trade Name | Cyclone XD |
| Number Of Flutes (Right Hand) | 2 |
| Diameter (Decimal Inch) | 0.1406 |
| Coolant-Thru | Yes |
| Included Angle | 140°-142° |
| Country of Origin | United States of America |
