M.A. Ford
CXDSR 1000AP
06566 CXD DRL 10.0MM SOLID REG
Specifications
| Coolant Fed | No |
|---|---|
| Number Of Flutes | 2 |
| Overall Length (Metric) | 103 |
| Diameter (Inch) | 0.39 |
| Material | Carbide |
| Diameter (Metric) | 10 |
| Unit Of Measure | Metric |
| Diameter | 10 mm |
| Flute Length | 61 mm |
| Shank Type | Straight |
| Helix Angle | 30 degrees |
| Series | Cyclone XD |
| Shank Diameter | 10 mm |
| Shank Diameter (Metric) | 10.00 |
| Included Angle | 140 degrees-142 degrees |
| Number Of Flutes (Right Hand) | 2 |
| Specification | DIN 6537 L |
| Country of Origin | USA |
| Base Item Number | CXDSR 1000AP |
| Coolant-Thru | No |
| Product Type | Industrial Supplies |
| Unit of Measure | Metric |
| Through Coolant | No |
| Trade Name | Cyclone XD |
| Diameter (Decimal Inch) | 0.3937 |
| Shank Diameter (mm) | 1.00 cm |
