M.A. Ford
CXDSS 0770AP
06683 CXD DRL 7.7MM SOLID STUB
Specifications
| Overall Length (Metric) | 79 |
|---|---|
| Material | Carbide |
| Number Of Flutes | 2 |
| Shank Type | Straight |
| Shank Diameter (Metric) | 8 |
| Helix Angle | 30° |
| Through Coolant | No |
| Flute Length (mm) | 4.1 cm |
| Overall Length (mm) | 7.9 cm |
| Trade Name | Cyclone XD |
| Number Of Flutes (Right Hand) | 2 |
| Diameter (Decimal Inch) | 0.3031 |
| Shank Diameter (mm) | 8.00 mm |
| Coolant-Thru | No |
| Included Angle | 140°-142° |
| Specification | DIN 6537 K |
| Country of Origin | United States of America |
