MICRO 100
QIT-100600X
QIT-100600X
Specifications
| Long Description | 0.1100" (2.8 mm) Min Bore DIA x 0.600" Max Bore Depth x 0.0250" Projection x 0.1875" (3/16) Shank DIA x 2.00" (2) Overall Length x 0.002" Corner Radius #32-64 - Carbide Quick Change - UN Thread - Single Point Right Hand, AlTiN Coated |
|---|---|
| Short Description | Quick Change - Right Hand - 0.1100" (2.8 mm) Min Bore DIA x 0.600" Max Bore Depth x 0.0250" Projection x 2.00" (2) OAL x 0.002" Corner Radius #32-64 - AlTiN Coated |
| Shank Diameter | 0.1875" (3/16) |
| Overall Length | 2.00" (2) |
| Thread Size | 32-64 |
| Projection | 0.0250" |
| Neck Diameter | 0.0750" (1.9 mm) |
| Coating | AlTiN |
| Corner Radius | 0.002" |
