MICRO 100

UP-50125-24X

Specifications

Long Description	0.5120" (13 mm) Min Bore DIA x 1.500" (1-1/2) Max Bore Depth x 0.1250" (1/8) Tooth Width x 0.1250" (1/8) Projection x 0.5000" (1/2) Shank DIA x 3.00" (3) Overall Length x 0.0625" (1/16) Radius - Carbide Undercut Full Radius Right Hand, AlTiN Coated
Short Description	Right Hand - 0.5120" (13 mm) Min Bore DIA x 1.500" (1-1/2) Max Bore Depth x 0.1250" (1/8) Tooth Width x 0.1250" (1/8) Projection x 3.00" (3) OAL x 0.0625" (1/16) Radius - AlTiN Coated
Shank Diameter	0.5000" (1/2)
Overall Length	3.00" (3)
Projection	0.1250" (1/8)
Neck Diameter	0.3650"
Coating	AlTiN
Radius	0.0625" (1/16)
