Midland Industries
940176M
MIDLAND INDUSTRIES 94 FPT 600 psi WOG Pressure -22 to 302 deg F Forged Brass Body Ball Valve Italian Ball Valve
Specifications
| Long Description | MIDLAND INDUSTRIES Ball Valve, 1-1/4 in Nominal, Connection Type: FPT x FPT, Full Port, 600 psi WOG, Handle Operator, Forged Brass Body, PTFE Seat, Brass Stem, PTFE Seal, Brass Gland/Steel Nut and Spring Inseat Trim, Steel Handle, Chromium-Plated Brass Ball, -22 to 302 deg F, Import, Additional Information: 150 psi WSP Saturated Steam Pressure, 1-1/4-11-1/2 Thread Size |
|---|---|
| Short Description | MIDLAND INDUSTRIES 940176M Ball Valve, 1-1/4 in Nominal, FPT x FPT, 600 psi WOG Pressure, -22 to 302 deg F |
| Body Material | Forged Brass |
| Handle Material | Steel |
| Connection Type | FPT x FPT |
| Temperature Rating | -22 to 302deg F |
| Application | For full range of liquids and gases |
| Seal Material | PTFE |
