Nachi
1574635
L9618 Aqua EX Oil Hole 25D - 2.7mm
Specifications
| Coating/Finish | AQUA EX |
|---|---|
| Drill Point Angle | 140 |
| Short Description | - Carbide Coolant-Thru Deep Hole Micro Drill - AQUA EX Coated For High Wear Resistance - Single Margin Design - 140° Point Angle - Precision h6 Ground Shank |
| Flute Length | 76 |
| Shank Type | Endmill Type Shank |
| Shank Size | 3 |
| Overall Length | 126 |
| Cutting Direction | Right |
| Diameter (Metric) | 2.7 |
| Flute Type | CONVENTIONAL SPIRAL |
| Point Length (in) | 0 |
| Neck Length | 78 |
| Coolant-Thru | Yes |
