RobbJack
M20-2000-05-10
M20-2000-05-10 M20 Series 20mm Diameter Solid Carbide Saw
Specifications
| Long Description | Our precision ground 20mm diameter solid carbide saws are best used for non-ferrous materials, such as aluminum, copper, and plastics. They have 10 teeth with a 10 degree rake angle, and a 5mm inside diameter. The saws are ground with ultra-precision tolerances, with thickness held to +.0002"/-0.0000". Typical depth of cut per pass is about 4 times the saw thickness. If the total depth of cut is more than 5 times the saw thickness or you need to have a slitting saw with the highest performance see the <a href="https://robbjack.com/tools/?type=saw&chars_feat=coarse&tool_line=M20">MK20-05-10</a> series saw. The recommended maximum total depth of cut with a M20-05-10 using an <a href="https://robbjack.com/tools/tool-detail/?tool_name=MSA-05">MSA-05</a> saw arbor is 0.107". |
|---|---|
| Short Description | 20mm Diam. Slitting Saw, 2mm Thick, 5mm ID, 10 teeth |
| Arbor Diameter | 5 |
| Tooth Count | 10 |
| GTIN | 662966661277 |
| Outside Diameter | 0.787402 |
| Coating | UNCOAT |
| Measurement System | mm |
| Bullet 1 | Coarse Tooth |
