RobbJack
M40-0600-10-36
M40-0600-10-36 M40 Series 40mm Diameter Solid Carbide Saw
Specifications
| Long Description | Our precision ground 40mm diameter solid carbide saws are best used for tougher materials like steel, stainless, and super alloys. They have 36 teeth with a 5 degree rake angle, and a 10mm inside diameter. The saws are ground with ultra-precision tolerances, with thickness held to +.0002"/-0.0000". Typical depth of cut per pass is about 2 times the saw thickness. If the total depth of cut is more than 5 times the saw thickness or you need to have a slitting saw with the highest performance see the <a href="https://robbjack.com/tools/?type=saw&chars_feat=fine&tool_line=M40">MK40-10-36</a> series saw. The recommended maximum total depth of cut with a M40-10-36 using an <a href="https://robbjack.com/tools/tool-detail/?tool_name=MSA-10">MSA-10</a> saw arbor is 0.383". |
|---|---|
| Short Description | 40mm Diam. Slitting Saw, 0.6mm Thick, 10mm ID, 36 teeth |
| Arbor Diameter | 10 |
| Tooth Count | 36 |
| GTIN | 662966661666 |
| Outside Diameter | 1.574803 |
| Coating | UNCOAT |
| Measurement System | mm |
| Bullet 1 | Fine Tooth |
