Sandvik Coromant
5742012
Sandvik Coromant 5742012
Specifications
| Overall Length (Metric) | 125 |
|---|---|
| Overall Length (Inch) | 4.92 |
| Shank Width (Inch) | 0.79 |
| Shank Width (Metric) | 20 |
| Insert Style | R/L151.20 |
| Base Item Number | 1060 |
| Max. Cutting Depth | 17 mm |
| Max. Cutting Depth (Decimal) | 0.67 |
| Max. Cutting Depth (Metric) | 17 |
| Max. Overhang (Decimal) | 1.02 |
| Max. Overhang (Metric) | 26 |
| Max. Work Piece Parting Diameter (Decimal) | 1.38 |
| Max. Work Piece Parting Diameter (Metric) | 35 |
| Product Type | Industrial Supplies |
| Unit of Measure | Metric |
| Weight | 0.809 LB |
| Short Description | T-Max® Q-Cut shank tool for parting and grooving |
| Series | T-Max Q-Cut |
| Direction Of Hand | Right |
| Unit Of Measure | Metric |
| Insert Compatibility | N151.2-300-5E |
| Shank Height | 20 mm |
| Shank Width | 20 mm |
| Shank Height (Decimal) | 0.79 |
| Shank Height (Metric) | 20 |
| ANSI Code | R151.20-2020-30 |
| Coolant Through | No |
| Overall Width (Decimal) | 0.8 |
| Overall Width (Metric) | 20.3 |
| Overall Height (Decimal) | 0.79 |
| Overall Height (Metric) | 20 |
| Insert Seat Size Code | 30 |
| Workpiece Side Body Angle | 0 degrees |
| Clamping Type Code | Clamp |
| Coolant Entry Style Code | 0: Without Coolant |
| Coolant Exit Style Code | 0: No Coolant Exit |
| Country of Origin | Sweden |
