Sandvik Coromant
5742865
Sandvik Coromant 5742865
Specifications
| Shank Diameter (Metric) | 32 |
|---|---|
| Series | U-Max |
| Direction Of Hand | Right |
| Overall Length (Inch) | 5.12 |
| Material | Steel |
| Shank Type | Cylindrical |
| Shank Diameter (Inch) | 1.26 |
| Cutting Diameter (Metric) | 32 |
| Cutting Diameter (Inch) | 1.26 |
| Overall Length (Metric) | 130 |
| Short Description | U-Max® square shoulder milling cutter |
| Unit Of Measure | Metric |
| Cutting Diameter | 32 mm |
| Shank Diameter | 32 mm |
| ANSI Code | R216.2-032 |
| Coolant Through | No |
| Center Cutting Capability | Yes |
| Tool Cutting Edge Angle | 90 degrees |
| Clamping Type | Screw/Clamp |
| Torque | 2 Nm |
| Coolant Entry Style Code | 0: Without Coolant |
| Cutting Pitch Differential | No |
| Damping Property | No |
| Country of Origin | China |
| Base Item Number | 1027 |
| Max. Depth Of Cut | 16 mm |
| Max. Depth Of Cut (Decimal) | 0.63 |
| Max. Depth Of Cut (Metric) | 16 |
| Max. Plunge Depth (Decimal) | 0.59 |
| Max. Plunge Depth (Metric) | 15 |
| Max. Rotational Speed | 9460 1/min |
| Maximum Depth Of Cut (Inch) | 0.63 |
| Maximum Depth Of Cut (Metric) | 16 |
| Maximum Ramping Angle | 90 degrees |
| Number Of Inserts | 1 |
| Product Type | Industrial Supplies |
| Unit of Measure | Metric |
| Weight | 1.81 LB |
