Sandvik Coromant
6239443
Sandvik Coromant 6239443
Specifications
| Shank Diameter (Metric) | 25 |
|---|---|
| Shank Diameter (Inch) | 0.98 |
| Series | CoroDrill 870 |
| Short Description | CoroDrill® 870 exchangeable tip drill |
| Unit Of Measure | Metric |
| Depth x Diameter Ratio | 8 x D |
| Shank Diameter | 25 mm |
| Coolant Through | Yes |
| ANSI Code | 870-2100-21L25-8 |
| Shank Type | Cylindrical |
| Cutting Diameter (Decimal) | 0.86 |
| Cutting Diameter (Metric) | 21.9 |
| Overall Length (Decimal) | 10.2 |
| Overall Length (Metric) | 259 |
| Point Length (Decimal) | 0.13 |
| Point Length (Metric) | 3.32 |
| Functional Length (Decimal) | 7.86 |
| Functional Length (Metric) | 199.68 |
| Usable Length (Decimal) | 7.06 |
| Usable Length (Metric) | 179.25 |
| Body Length (Decimal) | 7.17 |
| Body Length (Metric) | 182 |
| Achievable Hole Tolerance | H9 |
| Usable Length Diameter Ratio | 8.185 |
| Torque (ft lbf) | 1.033 |
| Torque (NM) | 1.4 |
| Coolant Pressure (Bar) | 15 |
| Coolant Entry Style Code | 1: Axial Concentric Entry |
| Country of Origin | Sweden |
| Base Item Number | 2023 |
| Body Length (Inch) | 7.17 |
| Coolant Pressure (lbf/in2) | 217.557 |
| Max. Cutting Diameter | 21.99 mm |
| Max. Cutting Diameter (Decimal) | 0.87 |
| Max. Cutting Diameter (Metric) | 21.99 |
| Max. Rotational Speed | 7000 1/min |
| Min. Cutting Diameter | 21 mm |
| Min. Cutting Diameter (Decimal) | 0.83 |
| Min. Cutting Diameter (Metric) | 21 |
| Product Type | Industrial Supplies |
| Unit of Measure | Metric |
| Weight | 1.138 LB |
| Height Packed Product Metric | 40 mm |
| Height Packed Product Imperial | 1.575 inch |
| ISO Code (packed) | 870-2100-21L25-8 |
| Length Packed Product Metric | 260 mm |
| Life Cycle State | 20 |
| ISO Code (unpacked) | 870-2100-21L25-8 |
| Length Packed Product Imperial | 10.236 inch |
