Sandvik Coromant
8039774
Sandvik Coromant 8039774
Specifications
| Overall Length (Inch) | 4 |
|---|---|
| Length Of Cut (Inch) | 0.5 |
| Shank Size (Inch) | 0.38 |
| Material | Solid Carbide |
| Number Of Flutes | 3 |
| Diameter (Inch) | 0.38 |
| Unit Of Measure | Imperial |
| Corner Radius (Decimal) | 0.19 |
| Neck Diameter (Decimal) | 0.36 |
| Short Description | CoroMill® Dura, Solid carbide end mill 3 flute |
| Country of Origin | United States |
| Overall Length | 4 Inch |
| Length of Cut | 0.5 Inch |
| Shank Size | 0.38 Inch |
| Series | CoroMill® Dura |
| Diameter | 0.38 Inch |
| ANSI Code | WK-AL-EBN-L-30375 N1BZ |
| Grade | N1BZ |
| Usable Length (Decimal) | 2.13 |
| Cutting Edge Count | 3 |
| Material Classification Level All | N |
| Base Item Number | 2131 |
| Neck Diameter (Inch) | 0.36 |
| Product Type | Industrial Supplies |
| Unit of Measure | Imperial |
| Height Packed Product Metric | 15 mm |
| Height Packed Product Imperial | 0.591 inch |
| ISO Code (packed) | WK-AL-EBN-L-30375N1BZ |
| Length Packed Product Metric | 114 mm |
| Life Cycle State | 20 |
| ISO Code (unpacked) | WK-AL-EBN-L-30375 N1BZ |
| Length Packed Product Imperial | 4.488 inch |
| EAN Code | 7323225879774 |
| Substrate Type | Carbide |
