Seco Tools
00099779
CCGT21.51
Specifications
| Coating/Finish | Uncoated |
|---|---|
| Thickness (Metric) | 2.38 |
| Corner Radius (Metric) | 0.40 |
| Material | Carbide |
| Included Angle | 80 degrees |
| Corner Radius (Inch) | 0.02 |
| Style | CC0602 |
| Thickness (Inch) | 0.09 |
| Short Description | ISO Turning Insert |
| Long Description | Seco CCGT21.51 ISO Turning Insert General Turning Inserts |
| Grade | 03G3 |
| Inscribed Circle Diameter | 0.25 Inch |
| Inscribed Circle Diameter (Metric) | 6.35 |
| Direction Of Hand | Neutral |
| Clearance Angle Major | 7 degrees |
| Cutting Edge Effective Length (Metric) | 6.10 |
| Cutting Edge Effective Length (Decimal) | 0.24 |
| Series | CCGT |
| ANSI Code | CCGT21.51 |
| Fixing Hole Diameter (Decimal) | 0.11 |
| Fixing Hole Diameter (Metric) | 2.80 |
| Number of Cutting Edges | 2 |
| Applicable Material | Grade 03g3-Uncoated Carbide-Non-Ferrous Materials |
| Theoretical Cutting Edge Length (Decimal) | 0.26 |
| Theoretical Cutting Edge Length (Metric) | 6.50 |
| Item Weight (lbs) | 0.002 |
| Insert Seat Size | 06 |
