Sowa Tool
123342
1/4"-28 UNF Yellow Ring HSSE-V3 Spiral Point Tap
Specifications
| Coating/Finish | Black Oxide |
|---|---|
| Number Of Flutes | 3 |
| Material | HSSE-V3 |
| Short Description | • Brand: Sowa High Performance Taps<br>• Thread Standard : UNF<br>• Overall Length (Inch) : 2-1/2"<br>• Thread Length (Decimal Inch) : 0.63 |
| Chamfer | 4.5P |
| Thread Limit | H3 |
| Through Coolant | No |
| Long Description | • Thread Size (Inch): 1/4"-28<br>• Chamfer: 4.5P<br>• Finish/Coating: Black Oxide<br>• Material: HSSE-V3<br>• Through Coolant: No<br>• Thread Direction: Right Hand<br>• Thread Limit: H3<br>• Number of Flutes: 3<br>HSSE-V3% Vanadium • Superior performance in hardened tool steels such as 4140, 4340, H13, D2. • Up to 35 HRC Designed for high-speed tapping applications. Developed to withstand the high stress and high heat associated with high-speed CNC production tapping. Features a unique free-cutting design with a special tempering and geometry which contributes to extra tool life. |
| Thread Size (Inch) | 1/4"-28 |
| Thread Direction | Right Hand |
