Sowa Tool
123679
M27 x 3mm Yellow Ring HSSE-V3 Spiral Flute Tap
Specifications
| Thread Limit | D7 |
|---|---|
| Number Of Flutes | 4 |
| Coating/Finish | Black Oxide |
| Material | HSSE-V3 |
| Short Description | • Brand: Sowa High Performance Taps<br>• Thread Standard : ISO Metric Coarse<br>• Overall Length (Inch) : 5-1/8"<br>• Thread Length (Decimal Inch) : 1.181<br>• Material Application : Steels & Other Materials Up To 35HRC |
| Chamfer | 2.5P |
| Flute Direction | Right |
| Thread Size (Metric) | M27x3 |
| Through Coolant | No |
| Long Description | • Thread Size (mm): M27x3<br>• Finish/Coating: Black Oxide<br>• Material: HSSE-V3<br>• Thread Direction: Right Hand<br>• Flute Direction: Right<br>• Through Coolant: No<br>• Chamfer: 2.5P<br>• Number of Flutes: 4<br>• Thread Limit: D7<br>HSSE-V3% Vanadium • Superior performance in hardened tool steels such as 4140, 4340, H13, D2. • Up to 35 HHRC Designed for high-speed tapping applications. Developed to withstand the high stress and high heat associated with high-speed CNC production tapping. Features a unique free-cutting design with a special tempering and geometry which contributes to extra tool life. |
| Thread Direction | Right Hand |
