Sowa Tool
124812
5/8"-11 UNC Yellow Ring HSSE-V3 DIN Length ANSI Shank Spiral Flute Tap
Specifications
| Thread Limit | H3 |
|---|---|
| Number Of Flutes | 4 |
| Coating/Finish | Black Oxide |
| Material | HSSE-V3 |
| Short Description | • Brand: Sowa High Performance Taps<br>• Thread Standard : UNC<br>• Overall Length (Decimal Inch) : 4.331"<br>• Thread Length (Decimal Inch) : 0.909<br>• Material Application : Steels & Other Materials Up To 35HRC |
| Chamfer | 2.5P |
| Flute Direction | Right |
| Through Coolant | No |
| Long Description | • Thread Size (Inch): 5/8"-11<br>• Finish/Coating: Black Oxide<br>• Material: HSSE-V3<br>• Thread Direction: Right Hand<br>• Flute Direction: Right<br>• Through Coolant: No<br>• Chamfer: 2.5P<br>• Number of Flutes: 4<br>• Thread Limit: H3<br>HSSE-V3% Vanadium • Superior performance in hardened tool steels such as 4140, 4340, H13, D2. • Up to 35 HRC • These taps combine ANSI shank specifications with advantage of DIN lengths for added reach |
| Thread Size (Inch) | 5/8"-11 |
| Thread Direction | Right Hand |
