Sowa Tool
124983
1/2"-20 UNF Orange Ring HSSE-V3 Spiral Flute Tap
Specifications
| Thread Limit | H3 |
|---|---|
| Number Of Flutes | 3 |
| Coating/Finish | Black Oxide |
| Material | HSSE-V3 |
| Short Description | • Brand: Sowa High Performance Taps<br>• Thread Standard : UNF<br>• Overall Length (Inch) : 3-3/8"<br>• Thread Length (Decimal Inch) : 0.769<br>• Material Application : Stainless Steel |
| Chamfer | 2.5P |
| Flute Direction | Right |
| Through Coolant | No |
| Long Description | • Thread Size (Inch): 1/2"-20<br>• Finish/Coating: Black Oxide<br>• Material: HSSE-V3<br>• Thread Direction: Right Hand<br>• Flute Direction: Right<br>• Through Coolant: No<br>• Chamfer: 2.5P<br>• Number of Flutes: 3<br>• Thread Limit: H3<br>HSSE-V3% Vanadium • Superior performance in stainless steels • Up to 35 HRC |
| Thread Size (Inch) | 1/2"-20 |
| Thread Direction | Right Hand |
