Sowa Tool
521026
CAT40 1/2" x 2.5" Dual Contact End Mill Holder
Specifications
| Taper Size | CAT40 |
|---|---|
| Long Description | • Shank Type: Taper Shank<br>• Taper Size: CAT40<br>• Hole Diameter (Inch): 1/2"<br>• Nose Diameter (Decimal Inch): 1.38<br>• Projection (Decimal Inch): 2.5<br>• Through Coolant: Yes<br>• Improves rigidity and reduces vibration allowing for increased feed rates and increased tool life<br>• DIN coolant option - standard<br>• All Ground Body<br>• Premium Balanced to 30,000 rpm<br>• Comes complete with certificate |
| Short Description | • Brand: GS Tooling<br>• Balanced to (RPM) : 30000<br>• Seat Depth (Decimal Inch) : 1.5<br>• Set Screw : 7/16-20 |
| Shank Type | Taper Shank |
| Through Coolant | Yes |
| Hole Diameter (Inch) | 1/2" |
