Sowa Tool
531048
CAT40 7/8" x 1.75" End Mill Holder
Specifications
| Taper Size | CAT40 |
|---|---|
| Long Description | • Shank Type: Taper Shank<br>• Taper Size: CAT40<br>• Hole Diameter (Inch): 7/8"<br>• Nose Diameter (Decimal Inch): 1.94<br>• Projection (Decimal Inch): 1.75<br>• Through Coolant: Yes<br>• DIN Coolant option - standard<br>• All Ground Body <br>• Premium balanced to 30,000 rpm <br>• Comes with certificate |
| Short Description | • Brand: GS Tooling<br>• Balanced to (RPM) : 30000<br>• Seat Depth (Decimal Inch) : 2.08<br>• Set Screw : 5/8"-18<br>• Notes : Stubby |
| Shank Type | Taper Shank |
| Through Coolant | Yes |
| Hole Diameter (Inch) | 7/8" |
