Sowa Tool
531162
CAT50 1-1/4" x 4.00" End Mill Holder
Specifications
| Taper Size | CAT50 |
|---|---|
| Long Description | • Shank Type: Taper Shank<br>• Taper Size: CAT50<br>• Hole Diameter (Inch): 1-1/4"<br>• Nose Diameter (Decimal Inch): 2.48<br>• Projection (Decimal Inch): 4<br>• Through Coolant: Yes<br>• DIN Coolant option - standard<br>• All Ground Body<br>• Premium balanced to 25,000 rpm<br>• Comes with certificate |
| Short Description | • Brand: GS Tooling<br>• Balanced to (RPM) : 25000<br>• Seat Depth (Decimal Inch) : 2.55<br>• Set Screw : 3/4-16 |
| Shank Type | Taper Shank |
| Through Coolant | Yes |
| Hole Diameter (Inch) | 1-1/4" |
