Sowa Tool
531310
CAT50 6.00" TG150 Collet Chuck
Specifications
| Taper Size | CAT50 |
|---|---|
| Long Description | • Collet System : Single Angle<br>• Collet Series: TG150<br>• Shank Type: Taper Shank<br>• Taper Size: CAT50<br>• Projection (Decimal Inch): 6<br>• DIN coolant thru the flange<br>• Shank traverse ground to obtain optimum accuracy<br>• Meets or exceeds ANSI specifications<br>• 0.0002" or better ensures the best possible cutting tool life<br>• Wrench not included<br>• Factory Balanced to save spindle life, tool life and increased productivity<br>• Threaded through holes for a back-up screw (tool stop) or coolant through when removed<br>• CAT40 Premium balanced to 20,000 rpm<br>• CAT50 Premium balanced to 15,000 rpm |
| Short Description | • Brand: GS Tooling<br>• Minimum Collet Capacity (Inch) : 1/2"<br>• Maximum Collet Capacity (Inch) : 1-1/2"<br>• Balanced to (RPM) : 15000<br>• Collet Nut Diameter (Decimal Inch) : 3.5<br>• Seat Depth (Decimal Inch) : 2.88<br>• Tightening Torque (Nm) : 94.9 |
| Shank Type | Taper Shank |
| Collet Series | TG150 |
