Sowa Tool
531429
CAT40 4.00" ER40 Collet Chuck
Specifications
| Taper Size | CAT40 |
|---|---|
| Long Description | • Collet System : ER<br>• Collet Series: ER40<br>• Shank Type: Taper Shank<br>• Taper Size: CAT40<br>• Projection (Decimal Inch): 4<br>• DIN Coolant option - standard<br>• All Ground Body <br>• Factory Balanced to save spindle life, tool life and increased productivity<br>• Threaded through holes for a back-up screw (tool stop) or coolant through when removed<br>• Wrench not included<br>• Premium balanced to G2.5 @ 30,000 rpm |
| Short Description | • Brand: GS Tooling<br>• Minimum Collet Capacity (Decimal Inch) : 0.118<br>• Maximum Collet Capacity (Decimal Inch) : 1.023<br>• Balanced to (RPM) : 30000<br>• Collet Nut Diameter (Decimal Inch) : 2.48<br>• Seat Depth (Decimal Inch) : 1.5<br>• Tightening Torque (Nm) : 219.6 |
| Shank Type | Taper Shank |
| Collet Series | ER40 |
