Sowa Tool
532128
BT30 2.50" TG75 Collet Chuck
Specifications
| Taper Size | BT30 |
|---|---|
| Long Description | • Collet System : Single Angle<br>• Collet Series: TG75<br>• Shank Type: Taper Shank<br>• Taper Size: BT30<br>• Projection (Decimal Inch): 2.5<br>• Shank traverse ground to obtain optimum accuracy<br>• Meets or exceeds ANSI specifications<br>• 0.0002" or better ensures the best possible cutting tool life<br>• Wrench not included<br>• Factory Balanced to save spindle life, tool life and increased productivity<br>• Threaded through holes for a back-up screw (tool stop) or coolant through when removed<br>• BT30/40 Premium balanced to 20,000 rpm<br>• BT50 Premium balanced to 15,000 rpm |
| Short Description | • Brand: GS Tooling<br>• Minimum Collet Capacity (Inch) : 3/64"<br>• Maximum Collet Capacity (Inch) : 3/4"<br>• Balanced to (RPM) : 30000<br>• Collet Nut Diameter (Decimal Inch) : 1.89<br>• Seat Depth (Decimal Inch) : 1.61<br>• Tightening Torque (Nm) : 81.3 |
| Shank Type | Taper Shank |
| Collet Series | TG75 |
