Sumitomo
10R4BBC
VNGG332RFY-AC1030U
Specifications
| Short Description | VNGG332RFY Grade AC1030U Carbide Turning Insert |
|---|---|
| Cutting Edge Length | 0.6535 |
| Inscribed Circle Diameter | 0.375 |
| Relief Angle | 0 |
| Tolerance Class | G |
| Series | AC1030U |
| Coating Process Type | PVD |
| Insert Holding Method | Pin & Clamp |
| Coating | Absotech |
| Hole Diameter | 3.81 |
| Corner Angle | 35 |
| Primary Workpiece Material | Steel, Stainless Steel, Small Machining |
| Insert Style | VNGG |
| Insert Size | 332 |
| Insert Thickness | 0.1874 |
| Secondary Workpiece Material | Steel, Stainless Steel, Small Machining |
