Sumitomo
2600ARW
GNDMR3232P-312
Specifications
| Series | GND |
|---|---|
| Short Description | Groove Width 3mm, 3.18mm, 0.118", 0.125", Max Groove Depth 12mm, Multi-Function OD Grooving Tool |
| Insert Width | 0.1181 |
| Shank Width | 32 |
| Shank Height | 32 |
| Head Length | 36.6 |
| Insert Compatibility | GCMN3002, 3mm, 3.18mm, 0.118", 0.125" |
| Insert Holding Method | Clamp |
| Toolholder Style | Multi-Function OD Grooving Tool |
| Overall Length (OAL) | 170 |
