Sumitomo
2600W84
GNDLL122K-075J
Specifications
| Series | GND |
|---|---|
| Short Description | Groove Width 2mm, 2.39mm, 0.078", 0.094", Max Groove Depth 0.75 Inch, Deep OD Grooving Tool, Internal Coolant |
| Insert Width | 0.0937 |
| Shank Width | 0.75 |
| Coolant Through | Yes |
| Shank Height | 0.75 |
| Head Length | 1.752 |
| Insert Compatibility | GCMN2094R0.5, 2mm, 2.39mm, 0.078", 0.094" |
| Insert Holding Method | Clamp |
| Toolholder Style | Deep OD Grooving Tool, Internal Coolant |
| Overall Length (OAL) | 5 |
