Sumitomo
2600W8K
GNDLR083JX-050J
Specifications
| Series | GND |
|---|---|
| Short Description | Groove Width 3mm, 3.18mm, 0.118", 0.125", Max Groove Depth 0.5 Inch, Deep OD Grooving Tool, Internal Coolant |
| Insert Width | 0.1181 |
| Shank Width | 0.5 |
| Coolant Through | Yes |
| Shank Height | 0.5 |
| Head Length | 0.878 |
| Insert Compatibility | GCMN3002, 3mm, 3.18mm, 0.118", 0.125" |
| Insert Holding Method | Clamp |
| Toolholder Style | Deep OD Grooving Tool, Internal Coolant |
| Overall Length (OAL) | 4.75 |
