Titan Cutting Tools
TT93414
212100
Specifications
| Thread Size | 1-11-1/2 |
|---|---|
| Long Description | 1-11-1/2 Size x 1.7500" (1-3/4) Thread Length x 1.1250" (1-1/8) Shank DIA, High Speed Steel Taper Pipe Tap - NPT, 5 Flutes, Uncoated |
| Overall Length | 3.7500" (3-3/4) |
| Short Description | 1-11-1/2 Size x 1.7500" (1-3/4) Thread Length x 1.1250" (1-1/8) Shank DIA, High Speed Steel - 5 FL - Uncoated |
| Shank Diameter | 1.1250" (1-1/8) |
| Flutes | 5 |
| Weight | 0.866 |
| Metric | N |
| Thread Length | 1-3/4 |
| Substrate | high speed steel |
| Type | NPT |
| Coating | UNCOATED |
| OAL | 3-3/4 |
| Length of Cut | 1.7500" (1-3/4) |
| Square Size | .843 |
| Square Length | 13/16 |
