YG-1
22000021
Carbide TURNING INSERT
Specifications
| Thickness (Metric) | 3.97 |
|---|---|
| Corner Radius (Metric) | 5 |
| Material | Carbide |
| Type | TURNING POSITIVE INSERT |
| Corner Radius (Inch) | 12/61 |
| Thickness (Inch) | 5/32 |
| Short Description | RCMT10T3M0YG801 |
| Grade | YG801 |
| Unit Of Measure | Imperial |
| Shape | Round |
| Clearance Angle | 7 degrees |
| Series | RCMT |
| Application | P,M,K,S,H |
| Thickness | 0.16 Inch |
| Insert Holding Method | Screw |
| Chip Breaker Side | One Side |
| Cutting Edge Angle | Round |
| Depth of Cut | 2.8 |
| Height Tolerance (Decimal) | 0.01 |
| Height Tolerance (Metric) | 0.13 |
| IC Tolerance (Decimal) | 0.01 |
| IC Tolerance (Metric) | 0.06 |
| Insert Diameter (Decimal) | 0.4 |
| Insert Diameter (Fractional) | 37/94 |
| Insert Diameter (Metric) | 10 |
| Thickness Tolerance (Decimal) | 0.01 |
| Thickness Tolerance (Metric) | 0.13 |
| Side Clearance | Positive |
| ANSI/ISO | ISO |
| Base Item Number | 22000021 |
| Product Type | Industrial Supplies |
| Unit of Measure | Imperial |
| Insert Thickness (Metric) | 3.96875 |
| Insert Style | TURNING POSITIVE INSERT |
| Insert Shape | Round |
