YG-1
68297CN
1/4 X 3/8 3 FL. REG. SE. BALL, ROUGHING, TIN COATED
Specifications
| Coating/Finish | TiN |
|---|---|
| Shank Type | Flat |
| Diameter (Metric) | 6.35 |
| Overall Length (Inch) | 2-7/16 |
| Length Of Cut (Inch) | 5/8 |
| Overall Length (Metric) | 61.91 |
| Cutting Direction | Right |
| Type | HSSCo8 3 Flute Regular Length Corase Pitch Roughing Ball Nose |
| Shank Size (Inch) | 3/8 |
| Material | HSSCo8 |
| Length Of Cut (Metric) | 15.88 |
| Number Of Flutes | 3 |
| Diameter (Inch) | 1/4 |
| Unit Of Measure | Fractional |
| Short Description | 3 FL. REG. SE. BALL, ROUGHING, TIN COATED |
| Shank Diameter (Decimal) | 0.38 |
| Shank Diameter (Metric) | 9.53 |
| Application | P |
| Length of Cut | 5/8 Inch |
| Series | E2193 |
| Diameter | 1/4 Inch |
| Workpiece Material | Steel |
| Ball Nose Radius (Decimal) | 0.13 |
| Ball Nose Radius (Metric) | 3.18 |
| Ball Nose Radius (Fractional) | 1/8 |
| Cut Type | Center Cut |
| Base Item Number | 3 FL. REG. SE. BALL, ROUGHING, TIN COATED |
| Product Type | Industrial Supplies |
| Unit of Measure | Fractional |
| Weight | 0.0730 |
| Shank Diameter (Inch) | 0.3750 |
| Size | 1/4 x 3/8 |
| Shank Style | Flat |
